PTD 901 [WES]
Throughfeed dishwasher With short cycles for large amounts of crockery - w/ integrated water softener.
- Max. cleaning performance*: 1296 plates/hDepending on site conditions (temperature of incoming water / power connection) values given may vary.Brilliant results in the shortest amount of time*
Thanks to the professional wash system, washed items can be used again quickly.Depending on site conditions (temperature of incoming water / power connection) values given may vary. - Always the right programme - item-specific solutionsSpecific programme for items to be washed
Regardless of the items and how dirty they are, there is an effective programme for all requirements. - Simple and flexible operation – full-touch displayFull-touch display
All the main information is accessible quickly and easily via the convenient full-touch display. - Optimum work flow - push-through basket systemOptimum work flow thanks to push-through system
Basket loading, washing and emptying can be designed as a continuous process. - Optimum suds filtering- first-class filter systemHighly effective filter system
Outstanding dishwashing results and reliability are largely due to the highly effective filter system.
Material machine front
Product benefits
Heat recovery system
Efficient
Saves costs: The recycling of waste water heat facilitates a high level of energy efficiency.
Proven hygiene
Effective against viruses – scientifically proven
Our tank dishwashers remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology for the PTD 70x can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/PTD70x_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2021-11-25.pdf. | A description of the relevant methodology for the PTD 901 can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/PTD901_Viruswirksamkeit_Testkriterien_virus_effectiveness_test_criteria_04.22.pdf.
Optimised spray arm
Efficient
Optimised nozzle design helps to achieve optimum surface coverage and efficient use of resources.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Heat recovery system
Efficient
Saves costs: The recycling of waste water heat facilitates a high level of energy efficiency.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Proven hygiene
Effective against viruses – scientifically proven
Our tank dishwashers remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology for the PTD 70x can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/PTD70x_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2021-11-25.pdf. | A description of the relevant methodology for the PTD 901 can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/PTD901_Viruswirksamkeit_Testkriterien_virus_effectiveness_test_criteria_04.22.pdf.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Optimised spray arm
Efficient
Optimised nozzle design helps to achieve optimum surface coverage and efficient use of resources.
Pressure booster pump
Full-size power
For optimum cleaning results for short wash cycles – irrespective of the local water pressure.
Spray arm control
Optimum wash results
If a spray arm is obstructed by crockery or cutlery, the display will indicate this.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Hygienic tank interior
No sharp corners or edges
Particularly hygienic: The thermoformed wash cabinet prevents deposits and reduces the time spent cleaning.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Optimum work flow thanks to push-through system
Perfectly organised
Basket loading, washing and emptying can be designed as a continuous process.
Internal dispenser unit for rinse aid
Optimum dosage
The rinse aid is dispensed automatically. The preset dosage can be altered if required.
A wide range of accessories
Optimum features
Always perfect ergonomics and efficiency - with practical accessories, from special baskets to dispenser pumps.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Product details
PTD 901 [WES]
EAN 4002516485384 / Article number 61090102D / Material number 11917900
EAN 4002516485384 / Article number 61090102D / Material number 11917900
| Construction type | Passthrough dishwasher Optimum work flow thanks to push-through system Basket loading, washing and emptying can be designed as a continuous process. |
|---|---|
| Range | Professional |
| Model | Performance |
| Wash system | Tank passthrough The tank dishwashing system for constant use One major advantage of the tank dishwashing system is the fact that the dishwasher is always ready for use. This is made possible by keeping the cleaning water available at the desired temperature, resulting in extremely short programme running times with outstanding cleaning results. |
| Number of levels | 1 |
| Front | Stainless steel |
| Tank volume in l | 35 |
| Suitable for retirement and care homes | |
|---|---|
| Suitable for hospitals | |
| Suitable for small restaurants/bars | |
| Suitable for hospitality industry | |
| Suitable for guesthouses | |
| Suitable for canteens | |
| Suitable for child care facilities | |
| Suitable for universities and schools | |
| Suitable for fast food restaurants | |
| Suitable for sports clubs |
| Tested virucidal efficacy | Effective against viruses – scientifically proven According to certification issued by the InFluenc_H – Institute for Integrative Hygiene and Virology, cleaning with tank dishwashers in programmes 1, 2 and 3 using Miele’s ProCare Shine 10 A and 10 GC cleaning agents removes enveloped viruses including not only the coronavirus, for example, but also noroviruses and adenoviruses. |
|---|---|
| Circulation pump Qmax in l/min. | 300 |
| Shortest programme duration in sec. Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 50 |
| Maximum final rinse temperature in °C | 90 |
| Cleaning performance, plates/h Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 1296 |
| Cleaning performance, glasses/h Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 3773 |
| Cleaning performance, baskets/h Performance data The values quoted may vary depending on the on-site conditions (power connection/water intake temperature). | 72 |
| Service life in wash cycles Note Our machines undergo intensive testing under laboratory conditions. The actual number of wash cycles may vary depending on actual usage behaviour, maintenance and care of the machine. | 438000 |
| Electrical connection | 3N AC 380-415V 50HZ |
|---|---|
| Heater rating in kW | 8.2 |
| Tank heater rating in kW | 2.5 |
| Boiler heater rating in kW | 10.8 |
| Total connected load in kW | 9.1 |
| Fuse rating in A | 16 |
| Length of mains connection cable in m Note The length refers to the supply lead on the outside of the appliance. | 3.5 |
| Electrical connection | 3N AC 380-415V 50HZ |
|---|---|
| Heater rating in kW | 10.8 |
| Total connected load in kW | 13.2 |
| Fuse rating in A | 25 |
| Electrical connection | 3N AC 380-415V 50HZ |
|---|---|
| Heater rating in kW | 11.7 |
| Total connected load in kW | 14.7 |
| Fuse rating in A | 32 |
| Cold or hot water [number] | 1 |
|---|---|
| Maximum temperature of inlet water in °C | 60 |
| Required flow pressure in bar | 1-6 |
| Drain pump [DN] | 19 |
| Drain pump head height from floor level, max. in c | 65 |
| Booster pump | |
| Integrated water softener | |
| Maximum water hardness in mmol/l Note With a water hardness level of 0.53 mmol/l and above, the installation of a pre-connected water softener is recommended if an integrated water softener is not already available. | 5.35 |
| Water consumption per wash cycle in l | 2.2 |
| Length of water inlet hose in cm | 150 |
| Length of water drain hose in cm | 150 |
| Maximum height adjustment in mm | 35 |
|---|---|
| External dimensions with closed hood, height Note The dimension refers to the appliance height without the feet extended. The height-adjustable feet allow the height of the dishwasher to be adjusted with ease. | 1535 |
| External dimensions with opened hood, height Note The dimension refers to the appliance height without the feet extended. The height-adjustable feet allow the height of the dishwasher to be adjusted with ease. | 2010 |
| External dimensions, net width in mm | 635 |
| External dimensions, net depth in mm | 750 |
| External dimensions, gross height in mm Note Including packaging | 1660 |
| External dimensions, gross width in mm Note Including packaging | 770 |
| External dimensions, gross depth in mm Note Including packaging | 880 |
| Usable space in wash cabinet, height in mm | 440 |
| Usable space in wash cabinet, width in mm | 540 |
| Usable space in wash cabinet, depth of lower basket in mm | 500 |
| Usable space in wash cabinet, depth in mm | 550 |
| In-feed height above floor in mm | 850 |
| Net weight [kg] | 137 |
| Gross weight in kg Note Including packaging | 151 |
| Maximum floor load in N/m² Maximum floor bearing capacity Maximum floor bearing capacity states the maximum weight (N) that can be placed on the supporting surface on which the machine is installed. This maximum load bearing capacity is the result of adding up the weight of the machine, the load and the water in it, as well as the dynamic forces that occur during operation. | 2026 |
| Emissions – sound pressure at workplace Emissions - sound pressure at workplace The emission sound pressure level depends on the programme and is a value given to the noise created by the machine. Miele Professional appliances have very low noise levels. | 62 dB(A) re 20 µPa |
|---|
| Programme for light soiling | |
|---|---|
| Programme for normal soiling | |
| Programme for heavy soiling | |
| Additional programme options | |
| Wash ware specific | |
| Soak | |
| Self-cleaning | |
| Descaling | |
| Basic cleaning |
| Integrated dispensing pump/dispensing module for rinsing agent | |
|---|---|
| Wash cabinet made from high-quality stai | |
| Spray arm monitor for all spray arms | |
| Manual hood operation | |
| Automatic programme start once hood is closed | |
| Adjustable final rinse temperature | |
| Adjustable wash temperature | |
| Adjustable rinse time | |
| Heat recovery from waste water | |
| Temperature indicator for tank and boiler | |
| Hygienic tank wash cabinet | |
| Rotating spray system (top + bottom) | |
| Pump protection filter | |
| A wide range of accessories (optional) |
| CE | |
|---|---|
| Complies with Machinery Directive 2006/42/EC | |
| Splash-proof IPX5 | |
| EMC radio suppressed | |
| DIN EN 17735 | |
| DIN SPEC 10534 | |
| WRAS | |
| UKCA |
