Product details
- Customised kitchen design - fully integrated in 702 mm width
- Unique user convenience –Con@ctivity
- Powerful – 600 m3/h in Booster level
- Efficient filtration-10-ply stainless-steel grease filter
- Safe and easy to clean -Miele CleanCover
- Manufactured with great care by
- Safety Information
Integrated extractor
Type of air guideCan be retrofitted
Recirculation conversion kit (order separately)DUU 151
Active charcoal filter (order separately)DKF 15-P
ColourStainless steel
Miele@home
Automatic function Con@ctivity
Electronic controls
ControlsLight-touch switches with LEDs
Miele@mobile app
Power levels (number without Booster level)3
Booster levels1
Programmable Booster level switch-off
Run-on time 5/15 min.
Grease filter saturation indicator
Grease filter saturation indicator
Active charcoal filter saturation indicator
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)A
Annual energy consumption in kWh/year51.7
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classB
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply)2
LED
Number x W2 x 3 W
Light intensity in Lx300 lx
Colour temperature in K3000 Kelvin
Dual-action blower
AC motor
Air throughput in Level 1 (m³/h) according to EN 61591250
Air throughput in Level 2 (m³/h) according to EN 61591300
Air throughput in Level 3 (m³/h) according to EN 61591360
Air throughput in Booster level 1 (m³/h) according to EN 61591600
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-351
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-356
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-367
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1332
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1337
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1341
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1352
Air throughput in Level 1 (m³/h) according to EN 61591200
Air throughput in Level 2 (m³/h) according to EN 61591250
Air throughput in Level 3 (m³/h) according to EN 61591320
Air throughput in Booster level 1 (m³/h) according to EN 61591530
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-355
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-359
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-363
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-372
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1344
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1348
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357
Safety shut-off
Canopy width in in. (mm)702
Canopy height in in. (mm)50
Depth of hood canopy in in. (mm)402
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg11.6
Length of supply lead in m1.5
Standard plug fitted
Total rated load in kW0.226
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm150
Combination with WiFi-enabled Miele hobrecommended
Non-return flap
EAN4002515978276
Non-return flap
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.
Automatic operation for intelligent fan control
Con@ctivity
Innovative convenience: the cooker hood reacts automatically to settings on the hob.
Automatic fan run-on
Run-on function
Odour-free room air: after cooking, the fan can be set to switch off automatically after a 5 or 15 minute run-on period.
Countdown time conveniently in view
Filter indicator
Easy filter replacement: a red light lets you know when the grease and/or active charcoal filter is saturated.
Automatic operation for intelligent fan control
Con@ctivity
Innovative convenience: the cooker hood reacts automatically to settings on the hob.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.
Always on the safe side
Safety switch-off
Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.
Matching products and accessories
Downloads
- 1.Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630
We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
