Dialog oven

DO 7860 Brilliant white

- from designer-level kitchen to star rated kitchen.

Colour:Brilliant white
Brilliant white
Graphite grey
Obsidian black
Stainless steel/Clean Steel

sale price£9,649.00



Product details

  • Innovative cooking every day in your own home thanks toM Chef
  • Improved results in terms of texture and uniformity
  • Demanding dishes made easy withGourmet AssistantandGourmet Pro
  • Multi-stage cooking with MChef Menu
  • Time savings of up to 70 % combined with excellent quality

Product data sheet

Dialog cooker
Appliance ColourBrilliant white
Back-lit M Chef logo
M Chef innovative cooking
Private Dining
Gourmet Profi
Gourmet Assistent
Pre-heating
Food probeYes
Keeping warm
Crisp function
Fan plus
Conventional heat
Moisture plus
Moisture plus with Conventional heat
Moisture plus with Fan plus
Moisture plus with Intensive bake
Moisture plus with Conventional heat
M Chef menu
M Chef + Fan plus
M Chef + Conventional heat
M Chef + Intensive bake
M Chef + Moisture plus
M Chef + Auto roast
M Chef + Fan grill
M Chef + Full grill
Extremely gentle defrosting
Intensive bake
Auto roast
Fan grill
Grill
Economy grill
Grill operating modes
Top heat
Bottom heat
Low temperature cooking
Automatic programmes
Special applications
Networking with Miele@home
DisplayM Touch
SoftOpen
MultiLingua
MyMiele
Help function
Programmable timed steam injection
Polyphonic buzzers
Timer functions
Time of day display
Clock synchronisation
Date display
Minute minder
Programmable start of cooking duration
Programmable cooking duration
Actual temperature display
Target temperature display
Buzzer when desired temperature is reached
Suggested Gourmet units
Recommended temperature
Sabbath programme
Individual settings
Automatic residual heat utilisation
Pyrolytic self-cleaning
Heated catalyser
Appliance cooling system and touch-cool front
Safety switch-off
System lock
Door lock during pyrolytic cleaning
Sensor lock
Oven compartment volume in l50
No. of shelf levels4
Oven lightBrilliantLight
Temperatures in °C30–300
Niche dimensions (W x H x D) in mm560-568 x 590-595 x 550
Niche width min. in mm560
Niche width max. in mm568
Niche height min. in mm590
Niche height max. in mm595
Niche depth in mm550
Appliance dimensions (W x H x D) in mm595 x 596 x 568
Weight in kg60.8
Total rated load in kW3.70
Voltage in V220-240
Frequency in Hz50
Fuse rating in A16
Number of phases1
Mains cable
Length of supply lead in m2
Replacing lampsService
Baking tray with PerfectClean1
Universal tray with PerfectClean1
Baking and roasting rack PyroFit1
Descaling tablets2
Available display languages via MultiLingua한국어
EAN4002516159865

What's included

Baking and roasting rack PyroFit (1)
Descaling tablets (2)
Baking tray with PerfectClean (1)
Universal tray with PerfectClean (1)

Setup/function

The only thing that gets hot is the food
Touch-cool front

Protection against burns: the appliance remains relatively cool – even on the outside of the door.


Convenient time settings
Clock synchronisation

Make your settings just once: the clocks on all networked Miele appliances are synchronised.


Reduce cooking odours
AirClean catalyser

Better air quality: almost all grease and odours are removed from the cooking vapours.


User convenience

Control and monitor things on the go
MobileControl

Anytime, anywhere: transfer data on the go or monitor/stop a cooking process using your smartphone.


Configure your appliance to suit you
Programmable settings

Suits you: you can individually configure the language, buzzers and display brightness.


Leave time management to the Dialog oven
Timer functions

Always on time: programme the start time, finish time and duration of the cooking process or the minute minder.


Cleverly networked
Domestic appliance networking with Miele@home1,

Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.


Oven cabinets

Outstanding illumination
BrilliantLight

A perfect view of your food: two LED light tubes illuminate your oven compartment evenly.


Efficiency and sustainability

Intelligent energy management
Residual heat utilisation

You benefit from environmentally friendly residual heat utilisation, which ensures intelligent energy management.


Special features

The latest innovation in cooking
M Chef

A new dimension in the culinary world: excellent results faster and with no compromise on quality.


Customised cooking
Gourmet Pro

Set all parameters to suit your needs and your dishes will be cooked exactly as you like them.


Expert advice
Gourmet Assistant

Advice from an expert: the Gourmet Assistant suggests appropriate settings for cooking your food.


Unique and unbeatable
M Chef menu

A menu at the touch of a button: different foods can be cooked together in the same step.


Perfect defrosting
Gentle defrosting

Even and fast: defrost food gently, with no compromise on quality and in no time at all.


Added moisture
M Chef with Moisture plus

Light dough, crispy crusts: additional moisture gives you incredible baking and roasting results.


Perfectly cooked without supervision
Food probe

For perfectly cooked meat or fish: the food probe will tell you when the required temperature is reached.


Tailored to specific requirements
Special applications

Making the extraordinary easy: special programmes such as gentle defrosting produce outstanding results.


Makes food crispy
Crisp function

Perfect for quiche or tarts: dry heat achieves a crispy, golden finish.


Safety

Maximum safety in any situation
Safety functions

Safety guaranteed: safety lock and safety switch-off provide reliable protection.


Operating modes

Gentle defrosting

Your frozen food is evenly defrosted and meets the same standards of quality as fresh ingredients.


M Chef + Fan plus

Perfectly soft and light: ideal for even quicker and more gentle baking, roasting and cooking.


M Chef + Conventional heat

For the classics: traditional baking and roasting recipes, perfectly cooked in no time at all.


M Chef + Intensive bake

Ideal for moist toppings: pizza, quiche or fresh fruit flans – crispy base, moist on top.


M Chef + Moisture plus

Unparalleled delights thanks to additional moisture: crusts browned to perfection and succulently tender fish.


M Chef + Auto roast

Cook meat quickly and succulently: the meat is seared at a high temperature, then roasted at a set temperature.


M Chef + Full grill

For intense flavour: time-saving grilling of larger quantities of sausages, kebabs, vegetables, etc.


M Chef + Fan grill

Crisp outside, succulent inside: ideal for rolled meat, poultry and many other meat dishes; reduced cooking time.


Fan plus

Perfectly soft and light: ideal for gentle baking and roasting on up to two levels.


Auto roast

Meat remains tender and succulent: meat is seared at a high temperature, then roasted at a selected temperature.


Full grill

Versatile function: perfect for grilling larger quantities of steaks, sausages, kebabs and more.


Economy grill

Designed for small quantities: ideal for small amounts of food such as steaks and sausages.


Intensive bake

Crispy bases, delicious toppings: pizza, quiche or fresh fruit flans – crispy base, moist on top.


Low temperature cooking

Tender and succulent: meat is cooked incredibly evenly at low temperatures without drying out on the outside.


Conventional heat

Multi-purpose, classic function: perfect results for all types of traditional baked and roasted dishes.


Top heat

Finishing touch for the eye and palate: perfect results when cooking gratins, baking toppings and browning food.


Bottom heat

Individual requirements: for cooking food in a bain-marie or for browning from underneath.


Fan grill

Crisp outside, succulent inside: ideal for chicken, duck, pork knuckle, rolled meat and many other meat dishes.


Moisture plus

As if fresh from the bakery: moisture ensures an incredibly light dough and a nicely browned crust.


Downloads

Product sheet
PDF
Downloads
UK declaration of conformity
PDF
Downloads
Warranty conditions
PDF
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
fbx
ZIP
Downloads
rvt
ZIP
Downloads
dwg
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000015/200001537/20000153700.png
Descriptions
DO7860, installation drawings
22 mm - glass, 23,3 mm - metal
Downloads
https://media.miele.com/images/2000015/200001537/20000153704.png
Descriptions
DO7860, installation drawings
1) Mains Connection cable, L = 1500 mm, 2) No connection in this area, 3) Lüftungsausschnitt min. 150 cm²
Downloads
https://media.miele.com/images/2000015/200001537/20000153701.png
Descriptions
DO7860, DO7860 C (CN), installation drawings, GB, AUS, CN
22 mm - glass, 23.3 mm - metal
Downloads
https://media.miele.com/images/2000015/200001537/20000153705.png
Descriptions
DO7860, DO7860 C (CN), installation drawings, GB, AUS, CN
1) Mains connection cable, L = 1500 mm, 2) No connection in this area, 3) Lüftungsausschnitt min. 150 cm²
Downloads
https://media.miele.com/images/2000015/200001537/20000153702.png
Descriptions
DO7860, DO7860C (CN), installation drawings
Installation drawings
Downloads
https://media.miele.com/images/2000015/200001537/20000153703.png
Descriptions
DO7860, DO7860C (CN), installation drawings
Installation drawings
Downloads
https://media.miele.com/images/2000015/200001537/20000153737.png
Descriptions
H7000 handle, glass, installation drawings
1) 400 mm, 2) 360 mm, 3) 47 mm, 4) 27 mm, 5) 32.5 mm
Downloads
  • 1.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
