Island cooker hood
PUR 98 D Stainless steel
with energy-efficient LED lighting and light-touch switches for easy use.
Colour:Stainless steel
sale price£2,299.00
Free Delivery with code FREESHIP at checkout. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630
You can select the following services for this product in your basket:
- Disconnect & Recycle Old Appliance (£20.00)
Product details
- Timeless design – stainless steel canopy 898 mm wide
- Powerful – 650 m3/h in Booster level
- Efficient filtration-10-ply stainless-steel grease filter
- Safe and easy to clean -Miele CleanCover
- Suitable for every home - for extraction or recirculation
Island cooker hood
Type of air guideCan be retrofitted
ColourStainless steel
Electronic controls
Booster levels1
Energy efficiency class (A+++ to D)A
Annual energy consumption in kWh/year51.8
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classA
Number of dishwasher-safe stainless steel grease filters (10-ply)3
Number x W4 x 3 W
Light intensity in Lx500 lx
Colour temperature in K3000 Kelvin
Dual-action blower
AC motor
Air throughput in Level 1 (m³/h) according to EN 61591280
Air throughput in Level 2 (m³/h) according to EN 61591330
Air throughput in Level 3 (m³/h) according to EN 61591400
Air throughput in booster level 1 (m³/h)650
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-348
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-357
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-369
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1331
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1335
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1351
Air throughput in Level 1 (m³/h) according to EN 61591190
Air throughput in Level 2 (m³/h) according to EN 61591270
Air throughput in Level 3 (m³/h) according to EN 61591330
Air throughput in Booster level 1 (m³/h) according to EN 61591460
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-357
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-362
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-366
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-373
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1340
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1345
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1349
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1356
Safety shut-off
Overall hood height for extraction mode and external in mm690–990
Overall hood height for recirculation and external in mm750–1060
Overall height for vented and external in in. (mm)690
Overall height for extraction mode and external mode cooker hoods in mm990
Overall height for recirculation in in. (mm)750
Overall height for recirculation mode cooker hoods in mm1060
Canopy width in in. (mm)898
Canopy height in in. (mm)70
Depth of hood canopy in in. (mm)598
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg34
Hard-wired connection
Total rated load in kW0.232
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm150
Telescopic chimney
Non-return flap
EAN4002516585794
Non-return flap
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Always on the safe side
Safety switch-off
Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.
