Built-in fridge-freezer combination

KFN 7734 C

DynaCool, convenient LED lighting and NoFrost for optimum storage.
Product data sheet
sale price£1,879.00
Free Delivery with code FREESHIP at checkout. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630


Additional services

You can select the following services for this product in your basket:

  • Disconnect & Recycle Old Appliance (£20.00)

Product details

  • Spacious drawer with moisture control –DailyFresh
  • Optimum and maintenance-freeLEDlighting in compartment
  • No icing up of food and no need to defrost thanks toNoFrost
  • Uniform temperature distribution inside the appliance –DynaCool
  • Dishwasher-proof door shelves –ComfortClean

Product data sheet

Fridge-freezer
Built-in appliance
Integrated appliance
Door hingeright
Convertible door hinging
Refrigeration section lightingLED
Networking with Miele@home
Freshness systemDailyFresh
ComfortClean
DynaCool
NoFrost
DuplexCool
ComfortSize
VarioRoom
SoftClose
Operating conceptSensorTouch
Fridge compartment can be switched offYes
Independent temperature regulation of fridge and freezer zones
Automatic SuperCool
SuperFreeze
No. of temperature zones2
Sabbath mode
Party mode
Holiday mode
No. of shelves5
including number of split shelves (FlexiBoard)1
No. of crisper drawers1
Number of inner door racks for tinned food2
Door rack for bottles1
Door shelves3
Number of freezer drawers3
Energy efficiency class (A–G)C
Annual energy consumption in kWh145.27
Energy consumption in 24 h in kWh0.397
Lock function
Acoustic door alarm
Acoustic temperature alarm
Optical door alarm
Optical temperature alarm
Power cut indication for freezer section
Niche width in mm min.560
Niche width in mm max.570
Niche height in mm min.1772
Niche height in mm max.1788
Niche depth in mm550
Appliance width in mm559
Appliance height in mm1770
Appliance depth in mm546
Weight in kg63.6
Door hinge technologyFixed door
Max. door front weight – refrigerator, in kg18
Max. door front weight – freezer, in kg12
Climate classSN-T
Refrigerator compartment in l183
4* freezer compartment in l70
Total usable capacity in l253
Storage time in case of fault in h9
Freezer capacity in kg/24 h6
Acoustic airborne noise emission class (A–D)B
Sound emissions in dB(A) re 1 pW33
Current consumption (mA)1400
Voltage in V220-240
Fuse rating in A13
Number of phases1
Frequency in Hz50-60
Length of supply lead in m2.2
Replacing lampsService
Egg tray
Ice cube tray
EAN4002516701422

What's included

Egg tray
Ice cube tray
Cleverly networked
Miele@home2,

Make your life smart: thanks to Miele@home2, , you can cleverly network your domestic appliances – for more options.

More space for tall containers
FlexiBoard

Particularly flexible: the FlexiBoard creates space for tall containers and preserves storage space in the rear.

User convenience

Pleasant atmosphere
LED lighting

Maintenance-free and economical: efficient and durable LEDs ensure perfect illumination of the interior.

Defrosting is a thing of the past
NoFrost

No more defrosting: the circulation cooling system prevents ice from developing, saving the hassle of defrosting.

Ideal storage conditions for food and wine
DynaCool

Even temperature distribution: a fan ensures excellent circulation and distribution of the cold air.

Dishwasher-safe door shelves
ComfortClean

Easy to clean: the high-quality door shelves can be cleaned easily in the dishwasher.

Convenient food storage
ComfortSize

Practical storage: the extensive depth makes it possible to place a whole baking tray on the bottom drawer level.

Cleverly networked
Miele@home2,

Make your life smart: thanks to Miele@home2, , you can cleverly network your domestic appliances – for more options.

Appliance door closes softly
SoftClose

Quiet and reliable closing: the gently self-closing doors prevent items from falling out.

More space for tall containers
FlexiBoard

Particularly flexible: the FlexiBoard creates space for tall containers and preserves storage space in the rear.

Special features

Improved freshness for fruit and vegetables
DailyFresh

Fruit and vegetables stay fresh for up to twice as long: spacious drawers with ideal humidity levels.

Matching products and accessories

Built-in freezer
FNS 7740 D

Built-in freezer

with NoFrost and 8 freezer drawers for max. convenience.

£2,399.00
Built-in freezer
FNS 7774 D

Built-in freezer

with IceMaker, NoFrost and 8 freezer drawers for max. convenience.

£2,799.00
Built-in freezer
FNS 7710 E

Built-in freezer

with NoFrost and 8 freezer drawers for max. convenience.

£2,099.00
Multi-purpose microfibre cloth, qty 1
GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

£6.79
MicroCloth kit, 3 pieces
GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

£13.59
Odour-absorbing Active AirClean filter
KKF-RF

Odour-absorbing Active AirClean filter

prevents unpleasant odours in the refrigerator.

£45.29
PerfectFresh organisation box
KSB 70

PerfectFresh organisation box

for orderly storage of food in the refrigerator.

£21.99
Pivotable glass shelf
KFT 7000

Pivotable glass shelf

with pivotable glass shelf for easy removal of items.

£220.49
Bottle rack
KFR 7000

Bottle rack

for safe, space-saving storage of bottles in the refrigerator.

£66.29
Starter set for Active AirClean filter.
KKF-FS

Starter set for Active AirClean filter.

prevents unpleasant odours in the refrigerator.

£54.99

Downloads

UK declaration of conformity
PDF
Downloads
UK declaration of conformity
PDF
Downloads
User manual
PDF
Downloads
Fitting Instructions
PDF
Downloads
Product sheet
PDF
Downloads
rvt
ZIP
Downloads
ifc
ZIP
Downloads
dwg
ZIP
Downloads
fbx
ZIP
Downloads
rfa
ZIP
Downloads
Energy label
PNG
Downloads
Energy label
PDF
Downloads
Product fiche
PDF
Downloads
Energy label
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000017/200001721/20000172161.png
Descriptions
KFN7734C, KFN7734F, KFN7734D, KFN7764D, KFN7785D, KFN7744E, KFN7774B, built-in (footnote*) (installation drawings)
*The declared energy consumption was calculated in a 560 mm deep niche. The appliance is fully functional in a 550 mm niche but the energy consumption will be slightly higher.
Downloads
https://media.miele.com/images/2000017/200001721/20000172160.png
Descriptions
KFN7734C, KFN7734F, KFN7734D, KFN7764D, KFN7785D, KFN7744E, KFN7774B, installation (footnote*) (installation drawings)
*1. View from the front, 2. Mains connection cable, L = 2100 mm, 3. Ventilation cut-out min. 200 cm², 4. Ventilation, 5. No connections permitted in this area
Downloads
https://media.miele.com/images/2000017/200001721/20000172162.png
Descriptions
KFNS7734D, KFN7734C, KFN7734F, KFN7734D, KFN7764D, KFN7785D, KFN7744E, KFN7774B, side view (installation drawings)
