Cooker hoods - DAH 2960 Escala Obsidian black - 1

Cooker hoods - DAH 2960 Escala Obsidian black - 2

Cooker hoods - DAH 2960 Escala Obsidian black - 3

Cooker hoods - DAH 2960 Escala Obsidian black - 4

Cooker hoods - DAH 2960 Escala Obsidian black - 5

Wall mounted cooker hood

DAH 2960 Escala Obsidian black

Name: DAH 2960 Escala
Brand: Miele
SKU: 12545640
Price: 1899 GBP
Availability: InStock

with Con@ctivity and smart touch controls for convenience

Product data sheet

Colour:Obsidian black

£1,899.00

Free Delivery with code FREESHIP at checkout. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630

Additional services

You can select the following services for this product in your basket:

Disconnect & Recycle Old Appliance (£20.00)

Product details

Lots of headroom – with glass canopy 898 mm wide
Unique user convenience –Con@ctivity
Efficient filtration-10-ply stainless-steel grease filter
Perfect match – glass panel and canopy in the same colour
Suitable for every home - for extraction or recirculation

Product data sheet

Wall mounted cooker hood

Type of air guideCan be retrofitted

Active charcoal filter (order separately)DKF 29 charcoal filter

ColourObsidian black

Edge extraction

Miele@home

Automatic function Con@ctivity

Electronic controls

ControlsComfortControl

ON/OFF switch

Power levels (number without Booster level)3

Booster levels1

Easy-to-clean canopy interior – CleanCover

Energy efficiency class (A+++ to D)B

Annual energy consumption in kWh/year72.3

Fluid dynamic efficiency classB

Lighting efficiency classA

Grease filtering efficiency classD

Easy-to-clean canopy interior – CleanCover

Number of dishwasher-safe stainless steel grease filters (10-ply)2

LED

Number x W1 x 3,2 W

Light intensity in Lx300 lx

Colour temperature in K3500 Kelvin

Dual-action blower

AC motor

Air throughput in Level 1 (m³/h) according to EN 61591215

Air throughput in Level 2 (m³/h) according to EN 61591315

Air throughput in Level 3 (m³/h) according to EN 61591415

Air throughput in booster level 1 (m³/h)675

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-341

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-347

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-353

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-365

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1327

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1333

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1339

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1351

Air throughput in Level 1 (m³/h) according to EN 61591190

Air throughput in Level 2 (m³/h) according to EN 61591280

Air throughput in Level 3 (m³/h) according to EN 61591380

Air throughput in Booster level 1 (m³/h) according to EN 61591575

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-354

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-360

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-371

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1333

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1340

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1346

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357

Safety shut-off

Single-ply safety glass (ESG)

Overall height for vented and external in in. (mm)830

Overall height for extraction mode and external mode cooker hoods in mm1210

Overall height for recirculation in in. (mm)443

Overall height for recirculation mode cooker hoods in mm443

Canopy width in in. (mm)898

Canopy height in in. (mm)443

Depth of hood canopy in in. (mm)388

Minimum height above electric hobs in mm450

Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650

Net weight in kg18

Length of supply lead in m1.3

Standard plug fitted

Total rated load in kW0.203

Voltage in V230

Fuse rating in A10

Frequency in Hz50

Number of phases1

Extraction ducting connection at top

Extraction connection at top and rear

Diameter of extraction ducting connection in mm150

Non-return flap

EAN4002516801504

What's included

Non-return flap

Automatic operation for intelligent fan control

Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.

Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Convenience and safety in detail

Miele CleanCover

Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

Features

Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Convenience and safety in detail

Miele CleanCover

Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

Decorative panels instead of metal grease filters

Edge extraction

Efficient and good-looking: with edge extraction, the grease filters are covered by a panel.

User convenience

Automatic operation for intelligent fan control

Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.

Safety

Always on the safe side

Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.

Matching products and accessories

GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

DAS 150

Aluminium vent hose

flexible vent duct.

DDF 125

Roof vent

for extraction.

DKF 29-S

Sensitive AirClean filter with active charcoal

for Miele DA 909x W, DA 929x W and DAH xxxx recirculation cooker hoods.

Matt black chimney

for alternative upward extraction ducting

Downloads

Warranty conditions

PDF

Downloads

Product sheet

PDF

Downloads

Operating instructions/Installation instructions

PDF

Downloads

Installation plan

PDF

Downloads

rvt

ZIP

Downloads

ifc

ZIP

Downloads

dwg

ZIP

Downloads

fbx

ZIP

Downloads

rfa

ZIP

Downloads

Energy label

PNG

Downloads

Energy label

PDF

Downloads

Product fiche

PDF

Downloads

Energy label

Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000020/200002057/20000205751.png

Descriptions

DAH2960 Installation drawings

1) Break-through if the mains connection is not made with a mains plug, but with a fixed connection., 2) Exhaust air opening ø 200 mm, so that the exhaust air line can be moved in the wall. Exhaust air connection ø 150 mm to the top or alternatively to the rear., 3) Air outlet for recirculated air. The distance to the ceiling or furniture mounted above the unit should be at least 300 mm.
