Gas hob

KM 3010 Stainless steel

Name: KM 3010
Brand: Miele
SKU: 9101190
Price: 1219 GBP
Availability: InStock

with 4 burners

Product data sheet

Colour:Stainless steel

£1,219.00

Free Delivery with code FREESHIP at checkout. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630

Additional services

You can select the following services for this product in your basket:

Disconnect & Recycle Old Appliance (£20.00)

Product details

Simple controls -single-handed operation via rotary dial control
Elegant design - 626 mm wide gas on glass hob
Versatile - 4 burners
Extremely safe -GasStop function
Easy cleaning - dishwasher-safe ComfortClean pot rests

Product data sheet

Heating typeGas

Independent of cooker

Ceramic surface colourBlack

Miele logo embossed in stainless steel

Cast iron pot rests (matt black enamelled)

Number of cooking zones4

Small burner in kW1

Medium burner in kW1.70

Large burner in kW2.70

Positionfront left

TypeHigh-speed burner

Positionrear left

TypeEconomy burner

Positionrear right

TypeStandard burner

Positionfront right

TypeStandard burner

Operation via knobs

Electronic ignition with single-hand operation

Dishwasher-proof pot rests

GasStop

GasStop & ReStart

Dimensions (W x D) in mm626 x 54 x 526

Dimensions in mm (width)626

Dimensions in mm (height)54

Casing height incl. connection box in mm63

Cut-out dimensions (W x D) with surface-mounted installation in mm600 x 500

Dimensions in mm (depth)526

Cutout dimensions in mm (width) with surface-mounted installation600

Cutout dimensions in mm (depth) with surface-mounted installation500

Weight in kg17

Total rated load in kW7.100

Position of gas connectionHinten links

Voltage in V220-240

Frequency in Hz50-60

Length of supply lead in m1.4

Jets for liquid gas

EAN4002515055830

What's included

Jets for liquid gas

Efficiently protects and makes cleaning easier

ComfortClean pot rests

Fast cleaning: Remove the pot rests and wash in the dishwasher. Keeps gas hobs looking good for longer.

Automatic reignition for extra safety

GasStop & ReStart

Safe cooking: Automatic re-ignition for flame failure Should this prove unsuccessful, the gas supply is turned off immediately.

The innovative

Gas hobs with electronic controls

More safety and convenience: Intelligent features make cooking with gas a great choice.

Features

The innovative

Gas hobs with electronic controls

More safety and convenience: Intelligent features make cooking with gas a great choice.

User convenience

Comfortably reignite the flame

Electronic ignition and single-handed controls

No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.

Everything under control

Front knob controls

Easy controls to regulate: Convenient power level control via plastic or metal knobs.

Maintenance

Efficiently protects and makes cleaning easier

ComfortClean pot rests

Fast cleaning: Remove the pot rests and wash in the dishwasher. Keeps gas hobs looking good for longer.

High quality features for a long life

Enamelled pot rests and burner parts

Nothing lasts longer and is easier to clean: enamelled cast-iron pot rests and burners with PerfectClean.

Efficiency and sustainability

Efficient and environmentally friendly

Gas - efficient and environmentally friendly

With environmental and economic benefits: Cooking with gas

Design

A gas hob to suit every kitchen style

Individual design

Attractive design to suit all tastes: a minimalist stainless-steel look or elegant ceramic glass.

Safety

Flame failure monitor for maximum safety

GasStop

Reassuring: if the flame is extinguished, for example by a draught, the continued supply of gas is prevented.

Automatic reignition for extra safety

GasStop & ReStart

Safe cooking: Automatic re-ignition for flame failure Should this prove unsuccessful, the gas supply is turned off immediately.

Matching products and accessories

GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

Fiskars “All Steel” starter pan set (4 pieces)

stainless steel cookware with a matt brushed finish exclusively for Miele.

CleanKitchen set

For cleanliness and shine throughout the kitchen.

KMBP 2800-2

Fiskars “All Steel” frying pan (28 cm)

made from stainless steel for lasting performance even at high temperatures.

KMKT 1825-2

Fiskars “All Steel” casserole (18 cm | 2.5 litres)

stainless steel cookware with a matt brushed finish exclusively for Miele.

KMKT 2460-2

Fiskars “All Steel” casserole (24 cm | 6 litres)

stainless steel cookware with a matt brushed finish exclusively for Miele.

KMKT 2040-2

Fiskars “All Steel” casserole (20 cm | 4 litres)

stainless steel cookware with a matt brushed finish exclusively for Miele.

Downloads

Operating instructions/Installation instructions

PDF

Downloads

Warranty conditions

PDF

Downloads

Product sheet

PDF

Downloads

ifc

ZIP

Downloads

fbx

ZIP

Downloads

rvt

ZIP

Downloads

rfa

ZIP

Downloads

dwg

ZIP

Downloads

Product fiche

PDF

Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000008/200000851/20000085154.png

Descriptions

KM 3010 G (Installation drawing)

1. Front, 2. Casing depth, 3. Mains connection box with mains connection cable L = 2000 mmm, 4. Gas connection R 1/2" - ISO 7-1 (DIN EN 10226)
