Product details
- No icing up of food and no need to defrost thanks toNoFrost
- Soft closing of the door withSoftClose
- Food is frozen quickly and gently –SuperFreeze
- Flexible increase in freezer volume –VarioRoom
Integrated appliance
Undercounter appliance
Door hingeright
Freezer compartment lightingLED
Networking with Miele@home
Operating conceptFreshTouch
No. of temperature zones1
Energy efficiency class (A–G)D
Annual energy consumption in kWh149.70
Energy consumption in 24 h in kWh0.411
Niche width in mm min.600
Niche width in mm max.600
Niche height in mm min.820
Niche height in mm max.880
Niche depth in mm560
Appliance width in mm597
Appliance height in mm818
Appliance depth in mm550
Weight in kg34
Door hinge technologyFixed door
Max. door front weight – refrigerator, in kg10
Climate classSN-T
4* freezer compartment in l74
Total usable capacity in l74
Storage time in case of fault in h12
Freezer capacity in kg/24 h8.20
Acoustic airborne noise emission class (A–D)B
Sound emissions in dB(A) re 1 pW32
Current consumption (mA)2000
Voltage in V220-240
Fuse rating in A10
Number of phases1
Frequency in Hz50-60
Length of supply lead in m2.2
Ice cube tray
EAN4002516779322
Ice cube tray
Cleverly networked
Miele@home2,
Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.
Cleverly networked
Miele@home2,
Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
KU7016D, KU7015D, KU7035D, KU7135C, FNUS7040D, FNUS7140C, Built-under, top view (installation drawings)
Installation drawings
Descriptions
KU7016D, KU7015D, KU7035D, FNUS7040D, Built-under, Einbauskizze, Nischenmaß (installation drawings)
Installation drawings
Descriptions
KU7016D, KU7015D, KU7035D, KU7135C, FNUS7140C, Built-under, installation drawing (*footnote) (installation drawings)
*1. View from the front, 2. Mains connection cable, L = 2200 mm, 3. No connection in this area
Descriptions
KU7016D, KU7015D, KU7035D, FNUS7040D, Built-under, side view (installation drawings)
